The NM Pedestal Series, with fixed head, can be adjusted to the millimetre in height by the use of the reinforced adjustment key, while any imperfections or inclines in the substrate can be compensated using the Twist Slope Compensator disc (TW110), adjustable with a simple twist.
Boasting a wide range of features that render it perfect for any number of raised flooring applications, including a Bi-material PP + Rubber anti-noise and anti-slip head, an adjustable height screw system that allows changes from above the finished floor, a pre-cut base for wall corner cuts and an above average tensile strength and a reliability that can only be offered by experts in the field of raised flooring supports, this product is regularly selected and widely appreciated throughout the building industry worldwide.
Advantages
Reinforced Adjustment Key
Pre-cut tabs for easy removal
Bi-material, PP + Rubber anti-noise and anti-slip head.
Coupling head to screw attachment system
PNM Extension capable of accommodating heights up to 930mm
Adjustable height screw system
Water drainage holes
205mm diameter / 320 cm2 smooth base support
Benefits
Finished floor height can be adjusted post installation thanks to the exclusive readjustment key system
Unique head design with non-slip and anti-noise rubber top
Use with TW110 to compensate for floor gradients of up to 2>#/li###
Entirely recyclable
Resistant to acids and ultraviolet deterioration
Resistant to temperatures ranging from -40 °C to +120°C
Suitable for any self-supporting outdoor paving system
Tile spacing tabs are strong, stable and easily removable
Indicator lines on base make cutting easy when installing pedestals into corners or end walls.
